Descripción

Referencia: 90MB0XX0-M0EAY0

Codigo: #12723

---

Cpu
intel® socket 1151 9th - 8th gen intel® core - pentium® gold and celeron®
processors
supports intel® 14 nm cpu
supports intel® turbo boost technology 3.0
* refer to www.asus.com for cpu support list
* the intel® turbo boost technology 3.0 support depends on the cpu
types.
chipset
intel® z390
memoria
4 x dimm - max. 64gb - ddr4
4266(o.c.) - 4133(o.c.) - 4000(o.c.) - 3866(o.c.) - 3733
(o.c.) - 3600(o.c.) - 3466(o.c.) - 3400(o.c.) - 3333(o.c.) - 3300(o.c.) - 3200(o.c.) - 30
00 (o.c.) - 2800(o.c.) - 2666 - 2400 - 2133 mhz non - ecc - un - buffered memory
dual channel memory architecture
supports intel® extreme memory profile (xmp)
* refer to www.asus.com for the memory qvl (qualified vendors lists).
* the maximum memory frequency supported varies by processor.
gráfica
integrated graphics processor - intel® uhd graphics support
multi - vga output support : hdmi - displayport ports
- supports hdmi with max. resolutión 4096 x 2160 @ 30 hz
- supports displayport with max. resolutión 4096 x 2304 @ 60 hz
supports intel® intru 3d - quick sync video - clear video hd technology -
insider
dp 1.2 multi - stream transport compliant - supports dp 1.2 monitor daisy
chain up to 3 displays
compatible multi - gpu
supports amd crossfirex technology
ranuras de expansión
1 x pcie 3.0 - 2.0 x16 (x16 or x8+x4+x4)
1 x pcie 3.0 - 2.0 x16 (max at x4 mode)
4 x pcie 3.0 - 2.0 x1
1 x m.2 socket (key e) - supports type 2230 wi - fi - bt and intel® cnvi
(integrated wi - fi - bt) module*
*for 3 ssd on cpu support - install a hyper m.2 x16 card (sold separately)
into the pciex16_1 slot - enable this card under bios settings.
* the wi - fi - bt module is purchased separately
almacenamiento
intel® z390 chipset :
1 x m.2 socket 3 - with m key - type 2242 - 2260 - 2280 storage devices support
(sata & pcie 3.0 x 4 mode)*1
1 x m.2 socket 3 - with m key - type 2242 - 2260 - 2280 storage devices support
(sata & pcie 3.0 x 2 mode)
4 x sata 6gb - s port(s)
support raid 0 - 1 - 5 - 10
intel® rapid storage technology supports
intel® optane memory ready
intel® cpu with intel® rapid storage technology support (raid 0 & raid 1)
pciex16_1 slot supports up to 3 intel® pcie nvme ssds via a hyper m.2
x16 series card
red
realtek® rtl8111h - support languard
audio
realtek® alc887 8 - channel high definitión audio codec
- supports : jack - detectión - front panel jack - retasking
audio feature :
- led - illuminated design - brighten up your build with the gorgeous
illuminated audio trace path.
- audio shielding: ensures precisión analog - digital separatión and greatly
reduced multi - lateral interference
- dedicated audio pcb layers: separate layers for left and right channels to
guard the quality of the sensitive audio signals
- premium japanese - made audio capacitors: provide warm - natural and
immersive sound with exceptiónal clarity and fidelity
* choose the chassis with hd audio module in front panel to support
8 - channel audio output.
puertos usb
intel® z390 chipset :
2 x usb 3.1 gen 2 port(s) (2 at back panel - - type - a)
intel® z390 chipset :
8 x usb 3.1 gen 1 port(s) (4 at back panel - - type - a - 4 at mid - board)
intel® z390 chipset :
3 x usb 2.0 - 1.1 port(s)
características especiales
fan xpert4
- advanced fan and liquid controls for ultimate cooling and quietness
asus 5x protectión iii :
- asus safeslot core: fortified pcie slot prevents damage
- asus languard: protects against lan surges - lightning strikes and
static - electricity discharges!
- asus overvoltage protectión: world - class circuit - protecting power
design - asus stainless - steel back i - o: 3x corrosión - resistance for
greater durability! - asus digi+ vrm: 9 phase digital power design
asus optimem ii
- optimem (improved ddr4 stability)
asus epu :
- epu
asus exclusive features :
- ai suite 3
- ai charger
asus quiet thermal solutión :
- stylish fanless design heat - sink solutión & mos heatsink
- asus fan xpert 4
asus ez diy :
- asus o.c. tuner
- asus crashfree bios 3
- asus ez flash 3
asus q - design :
- asus q - slot
- asus q - dimm
overclocking protectión :
- asus c.p.r.(cpu parameter recall)
m.2 onboard(the latest transfer technologies with up to 32gb - s data
transfer speeds)
memok! ii
- enhance memory compatibility. more smart and convenient. keep high
performance. (shorten the pc starting time)
q - installer
- auto download driver and software. friendly for first pc builder.
e - s panel trasero
1 x ps - 2 keyboard (purple)
1 x ps - 2 mouse (green)
1 x displayport
1 x hdmi
1 x lan (rj45) port(s)
2 x usb 3.1 gen 2 type - a -
4 x usb 3.1 gen 1 type - a -
3 x 8 - channel audio i - o
e - s internas
1 x lighting control rgb strip header(s)
2 x usb 3.1 gen 1(up to 5gbps) connector(s) support(s) additiónal 4 usb
3.1 gen 1 port(s)
1 x usb 2.0 1 - port connector(s) support(s) additiónal 1 usb 2.0 port(s)
1 x usb 2.0 connector(s) support(s) additiónal 2 usb 2.0 port(s)
1 x m.2 socket 1 with e key - type 2230 wi - fi - bt device support or intel®
cnvi (integrated wi - fi - bt) module
1 x m.2 socket 3 with m key - type 2242 - 2260 - 2280 storage devices support
(sata & pcie 3.0 x 4 mode)
1 x m.2 socket 3 with m key - type 2242 - 2260 - 2280 storage devices support
(sata & pcie 3.0 x2 mode)
1 x com port(s) connector(s)
4 x sata 6gb - s connector(s)
1 x cpu fan connector(s)
2 x chassis fan connector(s)
1 x aio_pump connector
1 x s - pdif out header(s)
1 x 8 - pin eatx 12 v power connector
1 x 24 - pin eatx power connector(s)
1 x front panel audio connector(s) (aafp)
1 x memok! ii switch(es)
1 x clear cmos jumper(s)
1 x system panel connector
accesorios
user's manual
i - o shield
2 x sata 6gb - s cable(s)
2 x m.2 screw package
1 x scd
bios
128 mb flash rom - uefi ami bios - pnp - sm bios 3.1 - acpi 6.1 -
multi - language bios - asus ez flash 3 - crashfree bios 3 - f11 ez tuning
wizard - f6 qfan control - f3 my favorites - last modified log - f9 search - f12
printscreen - and asus dram spd (seríal presence detect) memory
informatión disco de soporte
drivers
asus utilities
asus ez update
anti - virus software (oem versión)
sistema operativo
windows® 10 64 - bit
formato de fábrica
atx form factor
12.0 inch x 9.2 inch ( 30.5 cm x 23.4 cm )
solución de administración
wol by pme - pxe
